Weiwei U-shaped mixer machine

Categories：feed processing machines

Capacity：

Power：

Engine：

Applications：

 Tel：0086-371-63283021

 Email：admin@weiweimachinery.com

 WhatsApp：+8619838691608

Raw materials include sorghum, corn, soybean, wheat, rice, feed, etc. Stir well to meet various needs. Additives, probiotics, drugs, other grain powders, bone meal, fish meal and other protein additions

parameter

Mixer: 130kg/batch, 10-20 min/batch, three-phase, four-pole motor, 3kW, 1430 rpm,

Q235 steel plate

Housing thickness: 3.5mm

Overall Dimensions: 1050*650*1580 mm (Packaging dimensions, non-disassembled, 1.07 m³) Weight: 118.45 kg (excluding motor and reducer weight; reducer 20 kg)

Total volume: 0.24 m³

Hopper: 65 × 56 × 65 cm

Lower discharge port diameter: 13.5 cm

Distance from lower discharge port to ground: 82 cm

principle

The core working principle is as follows: The crushed raw materials are sent into a spiral elevator, which then lifts them to a U-shaped silo. After being mixed in the silo, they enter the particle machine pan through the discharge port, and are finally ground, extruded and granulated.

Detail

Suitable for various small and medium-sized feedlots, feed mills, and home-based farms.

Product Details and Packaging

Wooden crate packaging

Factory and more information

Zhengzhou Weiwei Machinery Co., Ltd. is a modern enterprise focusing on the research and development, manufacturing and export of animal breeding, agriculture and forestry machinery. The company has a standardized production workshop, and its main products have passed the EU CE certification and ISO9001 quality management system certification, which fully complies with international safety and environmental protection standards and provides reliable guarantee for equipment export.
