The 480-630 vertical grass kneading machine is a new type of grass chopper and shredder. It crushes both wet and dry grass, and the cutting length is adjustable. One machine therefore handles material that would otherwise call for separate equipment.
Adjustable length matters because different animals take forage at different lengths. Set the machine to the chop you need, and the same unit keeps working as the season changes, from fresh green grass to dry grass.
Output is 8 tons per hour, so the machine keeps up with daily feeding on a working farm rather than only with household use. For farms and small feed processing operations that cut grass all year, the wet-and-dry capability means the machine stays in use after the grass has dried.
Main specifications are listed below.
Model: 480-630
Motor: three-phase two-stage motor, 11kw / 15kw
Diesel engine: 15hp / 20hp
Weight: 160kg stand-alone, 250/270kg complete machine
Machine size: 120170190cm
Feed inlet: 65cm
Blade set: 3 guillotines, 16 flails, 8 serrated sharp knives, 24 kneading spinners
Hood shell sheet thickness: 5mm
Belt model: B1650
Hourly output: 8 tons
Barrel and wind silo: 480-630, with the wind tank behind the barrel
